BB5084
Box Blades
- Replaceable and adjustable ripper shanks
- iMatchTM compatible
- Replaceable and reversible blade
- Fixed tailgate
Features
Strong formed upper edge
The heavy-duty concave back plate, with a formed upper edge, provides added rigidity and strength for trouble-free performance.
BB Series Box Blade cutting edge is reversible
The BB Series Box Blade cutting edge ensures precise leveling and a fine finish. It is also reversible for twice the wear life.
The tailgates on the BB50 Series Box Blades are fixed, giving the cutting edge extra power to slice through hard, compacted ground.
Innovative hitch system
The iMatch Category 1 quick-attach hitch system is an innovative device that converts a 3-point hitch to fixed hooks and makes attaching implements an easy connection.
BB50 Series scarifier
Adjustments are easy on the BB50 Series Box Blades. Simply remove the steel pin and raise or lower the scarifier to increase or decrease ground penetration.
Scarifier shanks can be stored on the scarifier beam when using a box blade for other tasks.
Specifications
| Dimensions | BB5084 Current Model |
|---|---|
| Working width | 243.8 cm 96 in. |
| Unit height | 85.1 cm 33.5 in. |
| Unit depth | 78.7 cm 31 in. |
| Endplate thickness | 1 cm 0.375 in. |
| Moldboard thickness | 0.5 cm 0.1875 in. |
| Weight | |
| Operating weight | 273.1 kg 602 lb |
| Shipping | 288.9 kg 637 lb |
| Tractor compatibility | |
| PTO Horsepower | 20.1-41.8 kW 27-56 hp |
| Hitch | |
| Compatibility | Cat. 1 |
| iMatch™ compatible (Cat. 1) | Yes |
| Quick coupler (Cat. 2) | |
| Box | |
| Capacity | 0.6 m3 21.24 cu ft |
| Design | Box |
| Cutting edge | |
| Reversible | Yes |
| Quantity | Two |
| Size | 0.95x15.24 cm 0.375x6 in. |
| Scarifier shank and beam | |
| Shank type | 4 Position with holes |
| Points | Hardened, crimped |
| Quantity | Seven |
| Tubular scarifier beam size | 10.16x10.16x0.64 cm 4x4x0.25 in. |
| Beam reinforcement bar size | 1.27x1.27 cm 0.5x0.5 in. |
| Tailgate | |
| Type | Fixed |
| Mast | |
| Type | Welded |
| Paint | |
| Color | JD Green |
| Shipping | |
| Configuration | Two per crate |
| Set-up time | |
| Labor hours | 0.25 |
| Warranty | |
| Time period | 1 year |
